45W 4L/MIN Small dc electric diaphragm self-priming pump
Type:Diaphragm pump
Open flow:4L/MIN
Max power:45W
Customization:Customized logo/packaging/Graphic(Min. Order: 1000 Pieces)
Shipping:Support Express · Sea freight · Land freight · Air freight
Introduce
Specification
Application
Features: When the water pump outlet is closed or blocked, the pipeline pressure increases to the set value, the reflux valve is opened, the water flow circulates in the pump cavity, and the motor will be continually running. Therefore, the water spray hole size requirements are not high, with strong adaptability.
Application scope: High-pressure spraying equipment, agricultural spraying, and so on need high-pressure fog application occasions.
- Warranty:1 year
- Customized support:OEM, ODM
- Brand Name:Desun
- Model Number:0152HB-12-45,0152HB-24-45
- Place of Origin:Guangdong, China
- Application:Family Homes, Irrigation and Agriculture, Washing and Cleaning, Wastewater Transport and Flood Control
- Horsepower:45W
- Power Source:Electric
- Pressure:High Pressure, 108PSI
- Structure:Diaphragm Pump
- Cable Length:30CM
- Voltage:12V/24V
- Power:45W
- Theory:Micro Diaphragm Pumps
- Standard or Nonstandard:Standard
- Long life:2000Hours
- Workig temp.:less than 60degC
- Suction lift:1M
- Weight:0.7KG
- Duty work:Work a whole day continously
- Usage:liquid
- Certification:CE,RoHS
Mainly used for High – pressure fog – making, long – distance or mountain road trucks brake water cooling, pumping wine, milk, soy milk, drinking, cooking oil, and other liquids, Pumping gasoline, diesel, viscous liquids; Spray irrigation and water spraying, cleaning car, air contioner, vacuum cleaner， water purifier, etc…
We supply Full Customization Service, please contact us for the details.
