Micro air pump atomizer small air pump

  • Life:Expected life span is>=30,000 Times(on 10s/off 5s).
  • Low noise:≤60dB,far from 30cm distance.
  • Working conditions:Applying to indoor and outdoor under temperature 60 deg C.
  • Have suction function.can run continuously.
  • It can be powered directly by a Solar panel,DC electric source,or battery.
Introduce
Specification
Application
Product name
Mini air  Pump
Model
DSP030-XA
Working voltage
3~9V(DC)
Air flow
0.3~1L/MIN
Max.pressure
>=50kpa(375mmHg)
Leakage
<=3.0mmHg/min(from 300mmHg in a 100cc tank)
Material
Nylon material
Inflaiton time
<=8s(from 0 to 300mmHg in a 100cc tank)
Noise
≤ 60dB
Lifetime
>=30,000 Times(on 10s/off 5s)
Weight
14g
Outlet diameter
Dia 3.1mm
Dimensional drawing and working curve diagram

Widely used for Home appliances,medical,blackhead meters, breast pumps, vacuum packaging machines, massage machines, foam hand sanitizers, teeth flushers and other products; household appliances, medical treatment, beauty, massagers,adult products,Sphygmomanometers, Essential oil machines,Booster technology etc. Industries

Micro air pump atomizer small air pump application
