small electric high pressure agricultural sprayer pump
- Type:Diaphragam pump
- Maximum Flow Rate:6L/MIN
- Samples:Air pump
- Customization:Customized logo/packaging/Graphic(Min.Order:10oo Pieces)
- Shipping:Support Express-Sea freight-Land freight-Air freight
Features:
When the water pump outlet is closed or blocked,the pipeline pressure increases to the set value,the power supply will be automatically cut off to stop the motor；
The pressure reduces while reopening the water outlet,then the pressure switch will automatically turn on the power supply,and the motor rerun.
Application scope:
Car washer,solar energy automatic water,water system automatic control or other fluid automatic control auxiliary equipment,etc...
- Warranty:1year
- Customized support:OEM, ODM
- Brand Name:DESUN
- Model Number:5210YD-12-100G,5210YD-24-100G
- Place of Origin:Guangdong, China
- Application:Other,Family Homes,Irrigation and Agriculture,Mining industry,Water Distribution,Water Treatment Solutions
- Horsepower:Desun standard
- Power Source:Electric
- Pressure:162.8PSI
- Structure:Diaphragm Pump
- Voltage:12V
- Power:100W
- Product name:Diaphragm pump
- Max pressure:11KG
- Working pressure:7KG
- Suction Lift:1.5M
- Gunshot:9M
- Certification:CE,RoHS
Mainly used for High – pressure fog – making,long – distance or mountain road trucks brake water cooling,pumping wine,milk,soy milk,drinking,cooking oil,and other liquids,Pumping gasoline,diesel,viscous liquids;Spray irrigation and water spraying,cleaning car,air contioner,vacuum cleaner,water purifier,etc…
