Wholesales Customized 12V Diaphragm DC Air Pump
-
Type:Circulating Pumps,Air pump
- Samples:Air pump
- Customization:Customized logo/packaging/Graphic(Min. Order: 1000 Pieces)
- Shipping:Support Express · Sea freight · Land freight · Air freight
Features
- Life:Expected life span is over 50,000 times.
- One Year warranty.
- Duty work:The pump can sustain heavy-duty work for a whole day. Continuous operation.
- Working conditions:Applying to indoor and outdoor under temperature 45 deg C.
- Working temperature:5~45°C.
- One week for samples,two weeks for bulk order.
- Factory price+high quality+good after-sales service.
Related Parameters (The technical specification only for reference, it can be customized)
|
Voltage(V)
|
Power
|
Rated Current
|
Air tap O.D.
|
Air flow
|
Maximum Pressure
|
|
DC3V
|
2.4W
|
≤ 900mA
|
Dia 4.2mm
|
1 – 3.5 LPM
|
≥100KPa
|
|
DC 6V
|
2.4W
|
≤ 450mA
|
Dia 4.2mm
|
1 – 3.5 LPM
|
≥100KPa
|
|
DC 9V
|
2.4W
|
≤ 300mA
|
Dia 4.2mm
|
1 – 3.5 LPM
|
≥100KPa
|
|
DC 12V
|
2.4W
|
≤ 220mA
|
Dia 4.2mm
|
1 – 3.5 LPM
|
≥100KPa
|
|
DC 24V
|
2.4W
|
≤ 110mA
|
Dia 4.2mm
|
1 – 3.5 LPM
|
≥100KPa
|
Application:
1. Household applications:white goods,small appliances,fans,electric screens,automatic window opening,floor cleaning robots,vacuum cleaners,smart home systems.
2. Medical applications:medical pumps,sphygmomanometers,surgical tools,medical agitators,centrifuges.
3. Power tools:air pump,water pump,vacuum pump,oxygen generator,electric drill,electric screwdriver.
4. Commercial equipment:printers,copiers,shredders,projectors,scanners,cash registers,vending machines.
5. Personal care:hair dryer,electric shaver,beauty product,hair curler,steam hair straightener (water jet straight hai outlet).
6. Health field:massager,adult toy.
7. Security field:surveillance system,camera,safe.
8. Industrial applications:robotic arms,printing equipment,automation equipment.
9. Other applications:electronic door locks,smart switches,robots,toys,smart cars,boats,intelligent wear,electronics,DIY, etc.
